Energy Information at High Speed

Airflow

6719 Cubic Feet per Minute

Electricity Rate

34 Watts (excluded lights)

Airflow Efficiency

196 Cubic Feet Per Minute Per Watt

Downloads

Click Here to View Spec Sheet Details

Click Here to View Owners Manual

Product Specification

Item #

K7R0

Dimensions

Height: 13.78"

Width: 52.00"

Length: "

Additional product details

Category

Fan-Uni

Finish

Brushed Nickel

Option

Damp

Family

Kute5 52

Voltage

120 V

Additional Info

16 speed DC motor with reverse switch, fan speed, light controls, Fresh Air, Safe Exit, Sleep Timer and Home Away features , CHINA , Compatible with most smart home devices (recquired controls sold separately) , Energy Star Most Efficient 2021 , Set of (5) 52 inch Damp rated blades included with optional 16 watt LED CCT Select Light Kit (sold separately) , TR305 handheld remote with 23A battery included

Air Flow CFM

6719

Air Flow Efficiency

196

Amperage

0.48

Blade Finish

Brushed Nickel

Blade Pitch

Blade Span

Canopy

5.75 Dia x 2.51 H

Diameter

5.59

Down Rod Included

4.5

Electricity Used

Harmonized Codes

8414.51.3000

Length

Light Kit Included

Material

Composite

Motor Fan Speed

Motor RPM

158

Motor Size

100 X 30

Motor Type

Remote Control Included

TR305

Ship Carton Height

10.63

Ship Carton Length

30.31

Ship Carton Width

15.75

Ship Weight

20.5

Sold By

Each

Warranty

Limited Lifetime

Weight

15.21

Airflow Efficiency Low

413

Airflow Efficiency Medium

471

Avg Airflow Efficiency

184

Avg CFM Energy

4257

Avg Energy Use Watts

Avg Estimated Yearly Energy Cost

Avg Estimated Yearly Energy Cost on HIGH

Blade Finish Method

Painted

Blade Material

Composite

Blade Pitch Degrees

Blade Reversible

Blade Sweep

Canopy Diameter

5.75 Dia

Canopy Height

2.51 H

Cap Included

Yes

Carton Cubic Feet

2.94

Case Height

10.63

Case Length

30.31

Case Quantity

Case Weight Pounds

20.5

Case Width

15.75

CEC Uploaded

Yes

Ceiling To Blade Edge

12.5

Ceiling To Bottom

13.1 , 13.78

CFM Low

1098

CFM Medium

4052

Compatible Accessories

CCK8002BN, DR1-12BN, DR1-18BN, DR1-24BN, DR1-36BN, DR1-48BN, DR1-60BN, DR1-72BN, DR1-CPBN, SCB1-52

Compatible Light Kits

LK8534BN

Compatible Wall Controls

TW306

Country of Origin

China

Current Draw High

0.48

Current Draw Low

0.06

Current Draw Medium

0.14

Damp Rated

Yes

DOE Classification

LSSD

DOEFTC Uploaded

Yes

Downrod Length

4.5

Exempt from DOE Procedure

Fan Energy Star

Yes

Housing Diameter

5.59

Included Control

TR305

Included Control Type

Handheld

Leadwire

Light Kit Energy Star

Yes

Max Ceiling Slope

Max Watt

Maximum Slope Degree

Motor Finish Method

Plated

Motor Finish Method Type

Plated

Motor Reversible

Yes

Number of Blades

Number Of Speeds

Regulated Product

Yes

Reverse Switch Location

Control

RPM High (VI)

158

RPM Low (II)

RPM Medium (IV)

100

Safety Rating

UL Approved, cUL Approved

Voltage Cycles

60 hz

Watts Low

Watts Medium

Other Details:

16 Speed Dc Motor With Reverse Switch, Fan Speed, Light Controls, Fresh Air, Safe Exit, Sleep Timer And Home Away Features
Compatible With Most Smart Home Devices (recquired Controls Sold Separately)
Energy Star Most Efficient 2021
Set Of (5) 52 Inch Damp Rated Blades Included With Optional 16 Watt Led Cct Select Light Kit (sold Separately)
Tr305 Handheld Remote With 23a Battery Included

Ceiling To Bottom

Additional options that would change other selections

Call for Price

Qty:

BASE PRICE:

396

/ / 1

($396.00 / 1)
