Energy Information at High Speed

Airflow

5674 Cubic Feet per Minute

Electricity Rate

76 Watts (excluded lights)

Airflow Efficiency

75 Cubic Feet Per Minute Per Watt

Downloads

Click Here to View Spec Sheet Details

Click Here to View Owners Manual

Product Specification

Item #

K6T2

Dimensions

Height: 10.54"

Width: 60.00"

Length: "

Additional product details

Category

Fan-Uni

Finish

Black

Option

Wet

Family

Edgewood 60

Voltage

120 V

Additional Info

3 speed AC motor with reverse switch , 5674 CFM on High , Limited Lifetime Warranty , Pull Chain Operated , Set of (5) wet rated blades in multiple finish options included and light kit adaptable (sold separa , WiFi or bluetooth compatible (required controls sold separately)

Air Flow CFM

5674

Air Flow Efficiency

Amperage

0.64

Blade Finish

Black

Blade Pitch

13.5

Canopy

5.97 Dia x 2.36 H

Diameter

12.6

Down Rod Included

4.5

Electricity Used

Harmonized Codes

8414.51.3000

Length

Light Kit Included

Material

Composite

Max Height

14.17

Motor Fan Speed

Motor RPM

133

Motor Size

188 x 25

Motor Type

Ship Carton Height

11.3

Ship Carton Length

27.09

Ship Carton Width

15.2

Ship Weight

30.2

Sold By

Each

Warranty

Limited Lifetime

Weight

26.68

Airflow Efficiency Low

130

Airflow Efficiency Medium

Avg Airflow Efficiency

Avg CFM Energy

4331

Avg Energy Use Watts

Avg Estimated Yearly Energy Cost

Avg Estimated Yearly Energy Cost on HIGH

Blade Finish Method

Injected

Blade Material

Composite

Blade Reversible

Blade Sweep

Canopy Diameter

5.97 Dia

Canopy Height

2.36 H

Cap Included

Carton Cubic Feet

2.69

Cartons Per Unit

Case Height

11.3

Case Length

27.09

Case Quantity

Case Weight Pounds

30.2

Case Width

15.2

CEC Uploaded

Yes

Ceiling To Blade Edge

8.93/12.56

Ceiling To Bottom

10.54/14.17

CFM Low

2809

CFM Medium

4327

Compatible Accessories

DR1-CPBL, DR1SS-12BLW, DR1SS-18BLW, DR1SS-24BLW, DR1SS-36BLW, DR1SS-48BLW, DR1SS-60BLW, DR1SS-72BLW, SCK1-52BLW

Compatible Controls

BTCR9, BTR9, CR500, CRL4WH, WFR50

Compatible Light Kits

F5BL, F6BL, F8BL, G1FW, G1MS, G1TST, G2OP, G2TST, G3CL, G3OP, G3OPS, G4CL, G4OPS, G4TST, G5OP, G5TST, G6CL, G6OP, G6TST, LK179BLW

Compatible Wall Controls

CW5LA, CW5WH, CWRL4LA, CWRL4WH, WC1WH, WC2WH, WR500WH, WR501WH

Country of Origin

China

Current Draw High

0.64

Current Draw Low

0.34

Current Draw Medium

0.49

DOE Classification

LSSD

DOE-FTC Uploaded

Yes

DOEFTC Uploaded

Yes

Downrod Length

4.5

Exempt from DOE Procedure

Fan Energy Star

Housing Diameter

12.6

Included Control Type

Pull Chain

Leadwire

Max Ceiling Slope

Max Watt

Maximum Slope Degree

Motor Finish Method Type

Painted

Motor Reversible

Yes

Number of Blades

Number Of Speeds

Regulated Product

Yes

Reverse Switch Location

Switch Housing

RPM High (VI)

133

RPM Low (II)

RPM Medium (IV)

100

Safety Rating

UL Approved, cUL Approved

Voltage Cycles

60 hz

Watts Low

Watts Medium

Wet Rated

Yes

Other Details:

3 Speed Ac Motor With Reverse Switch
5674 Cfm On High
Limited Lifetime Warranty
Pull Chain Operated
Set Of (5) Wet Rated Blades In Multiple Finish Options Included And Light Kit Adaptable (sold Separately)
Wifi Or Bluetooth Compatible (required Controls Sold Separately)

Call for Price

Qty:

BASE PRICE:

320

/ / 1

($320.00 / 1)
