Energy Information at High Speed

Airflow

4180 Cubic Feet per Minute

Electricity Rate

61 Watts (excluded lights)

Airflow Efficiency

69 Cubic Feet Per Minute Per Watt

Downloads

Click Here to View Spec Sheet Details

Click Here to View Owners Manual

Product Specification

Item #

K6RW

Dimensions

Height: 10.03"

Width: 44.00"

Length: "

Additional product details

Category

Fan-Uni

Finish

Dark Bronze

Option

Wet

Family

Edgewood 44

Voltage

120 V

Additional Info

3 speed AC motor with reverse switch , 4180 CFM on High , Limited Lifetime Warranty , Pull Chain Operated , Set of (5) wet rated blades in multiple finish options included and light kit adaptable (sold separa , WiFi or bluetooth compatible (required controls sold separately)

Air Flow CFM

4180

Air Flow Efficiency

Amperage

0.51

Blade Finish

Dark Walnut

Blade Pitch

Canopy

5.97 Dia x 2.36 H

Diameter

11.42

Down Rod Included

4.5

Electricity Used

Harmonized Codes

8414.51.3000

Length

Light Kit Included

Material

Composite

Max Height

13.66

Motor Fan Speed

Motor RPM

204

Motor Size

153 X 18

Motor Type

Ship Carton Height

10.51

Ship Carton Length

20.79

Ship Carton Width

13.62

Ship Weight

19.18

Sold By

Each

Warranty

Limited Lifetime

Weight

17.2

Airflow Efficiency Low

158

Airflow Efficiency Medium

100

Avg Airflow Efficiency

Avg CFM Energy

3010

Avg Energy Use Watts

Avg Estimated Yearly Energy Cost

Avg Estimated Yearly Energy Cost on HIGH

Blade Finish Method

Painted

Blade Material

Composite

Blade Reversible

Blade Sweep

Canopy Diameter

5.97 Dia

Canopy Height

2.36 H

Cap Included

Carton Cubic Feet

1.72

Cartons Per Unit

Case Height

10.51

Case Length

20.79

Case Quantity

Case Weight Pounds

19.18

Case Width

13.62

CEC Uploaded

Yes

Ceiling To Blade Edge

8.35 / 11.98

Ceiling To Bottom

10.03 / 13.66

CFM Low

1684

CFM Medium

3037

Compatible Accessories

DR1-CPDZ, DR1SS-12DZW, DR1SS-18DZW, DR1SS-24DZW, DR1SS-36DZW, DR1SS-48DZW, DR1SS-60DZW, DR1SS-72DZW, SCK1-52DZW

Compatible Controls

BTCR9, BTR9, CR500, CRL4WH, WFR50

Compatible Light Kits

F5DZ, F6DZ, F8DZ, G1FW, G1MS, G1TST, G2OP, G2TST, G3CL, G3OP, G3OPS, G4CL, G4OPS, G4TST, G5OP, G5TST, G6CL, G6OP, G6TST, LK179DZW

Compatible Wall Controls

CW5LA, CW5WH, CWRL4LA, CWRL4WH, WC1WH, WC2WH, WR500WH, WR501WH

Country of Origin

China

Current Draw High

0.51

Current Draw Low

0.22

Current Draw Medium

0.37

DOE Classification

LSSD

DOE-FTC Uploaded

Yes

DOEFTC Uploaded

Yes

Downrod Length

4.5

Exempt from DOE Procedure

Fan Energy Star

Housing Diameter

11.42

Included Control Type

Pull Chain

Leadwire

Max Ceiling Slope

Max Watt

Maximum Slope Degree

Motor Finish Method Type

Painted

Motor Reversible

Yes

Number of Blades

Number Of Speeds

Regulated Product

Yes

Reverse Switch Location

Switch Housing

RPM High (VI)

204

RPM Low (II)

RPM Medium (IV)

142

Safety Rating

UL Approved, cUL Approved

Voltage Cycles

60 hz

Watts Low

Watts Medium

Wet Rated

Yes

Other Details:

3 Speed Ac Motor With Reverse Switch
4180 Cfm On High
Limited Lifetime Warranty
Pull Chain Operated
Set Of (5) Wet Rated Blades In Multiple Finish Options Included And Light Kit Adaptable (sold Separately)
Wifi Or Bluetooth Compatible (required Controls Sold Separately)

Call for Price

Qty:

BASE PRICE:

260

/ / 1

($260.00 / 1)
