Energy Information at High Speed

Airflow

12900 Cubic Feet per Minute

Electricity Rate

33 Watts (excluded lights)

Airflow Efficiency

386 Cubic Feet Per Minute Per Watt

Downloads

Click Here to View Spec Sheet Details

Click Here to View Owners Manual

Product Specification

Item #

K7RW

Dimensions

Height: 21.08"

Width: 64.00"

Length: "

Additional product details

Category

Fan-Multi

Finish

Matte Greige

Option

Damp

Family

Spitfire

Voltage

120 V

Additional Info

12900 CFM on High , 16 speed DC motor with reverse switch, fan speed, light controls, Fresh Air, Safe Exit, Sleep Timer and Home Away features , CHINA , Compatible with most smart home devices (recquired controls sold separately) , Energy Star Most Efficient 2022 , Set of (3) Damp rated blades with multiple finishes available and 18 watt CCT Select LED light kit available (sold separately) , TR305 handheld remote with 23A battery included

Air Flow CFM

12900

Air Flow Efficiency

386

Amperage

0.47

Blade Pitch

Canopy

8.19 Dia x 2.2 H

Diameter

8.07

Down Rod Included

Electricity Used

Harmonized Codes

8414.51.3000

Length

64, 72, 84, 96

Light Kit Included

Max Length

Max Width

Motor Fan Speed

Motor RPM

112

Motor Size

153 x 25

Motor Type

Remote Control Included

TR305

Ship Carton Height

10.94

Ship Carton Length

14.37

Ship Carton Width

10.43

Ship Weight

15.61

Sold By

Each

Warranty

Limited Lifetime

Weight

14.18

Airflow Efficiency Low

1049

Airflow Efficiency Medium

880

Avg Airflow Efficiency

376

Avg CFM Energy

7429

Avg Energy Use Watts

Avg Estimated Yearly Energy Cost

Avg Estimated Yearly Energy Cost on HIGH

Blade Pitch Degrees

Canopy Diameter

8.19 Dia

Canopy Height

2.2 H

Cap Included

Carton Cubic Feet

0.95

Case Height

10.94

Case Length

14.37

Case Quantity

Case Weight Pounds

15.61

Case Width

10.43

CEC Uploaded

Yes

Ceiling To Blade Edge

19.42

Ceiling To Bottom

19.42 , 21.08

CFM Low

2958

CFM Medium

7355

Compatible Accessories

CCK6721GR, DR1-12GR, DR1-18GR, DR1-24GR, DR1-36GR, DR1-48GR, DR1-60GR, DR1-72GR, DR1-CPGR, SCK1-52GR

Compatible Blades

B6720-64BL, B6720-64BN, B6720-64DF, B6720-64DWA, B6720-64MW, B6720-64N, B6720-64WE, B6720-64WK, B6720-64WW, B6720-72BL, B6720-72BN, B6720-72DF, B6720-72DWA, B6720-72MW, B6720-72N, B6720-72WE, B6720-72WK , B6720-72WW, B6720-84BL, B6720-84BN, B6720-84DF, B6720-84DWA, B6720-84MW, B6720-84N, B6720-84WE, B6720-84WK, B6720-84WW, B6720-96BL, B6720-96BN, B6720-96DF, B6720-96DWA, B6720-96MW, B6720-96N, B6720-96WE, B6720-96WK, B6720-96WW

Compatible Light Kits

LK6721BDCGR

Compatible Wall Controls

TW306

Country of Origin

China

Current Draw High

0.47

Current Draw Low

0.06

Current Draw Medium

0.14

Damp Rated

Yes

DOE Classification

LSSD

DOEFTC Uploaded

Yes

Downrod Length

Exempt from DOE Procedure

Fan Energy Star

Yes

Housing Diameter

8.07

Included Control

TR305

Included Control Type

Handheld

Leadwire

Light Kit Energy Star

Yes

Max Ceiling Slope

Max Watt

Maximum Slope Degree

Motor Finish Method

Painted

Motor Finish Method Type

Painted

Motor Reversible

Yes

Number of Blades

Number Of Speeds

Regulated Product

Yes

Reverse Switch Location

Control

RPM High (VI)

112

RPM Low (II)

RPM Medium (IV)

Safety Rating

UL Approved, cUL Approved

Voltage Cycles

60 hz

Watts Low

Watts Medium

Other Details:

12900 Cfm On High
16 Speed Dc Motor With Reverse Switch, Fan Speed, Light Controls, Fresh Air, Safe Exit, Sleep Timer And Home Away Features
Compatible With Most Smart Home Devices (recquired Controls Sold Separately)
Energy Star Most Efficient 2022
Set Of (3) Damp Rated Blades With Multiple Finishes Available And 18 Watt Cct Select Led Light Kit Available (sold Separately)
Tr305 Handheld Remote With 23a Battery Included

Ceiling To Bottom

Additional options that would change other selections

Call for Price

Qty:

BASE PRICE:

340

/ / 1

($340.00 / 1)
